K1 Stainless Steel Flat Jet Steam Air Nozzles

The K1 Stainless Steel Flat Jet Steam Air Nozzles of air or steam has an extremely short effective spray angle, which is different from liquids.

Material
● Brass
● 303 Stainless steel
● 304 Stainless steel
● 316 stainless steel
Availability:
Product Description

K1 Stainless Steel Flat Jet Steam Air Nozzles

The K1 Stainless Steel Flat Jet Steam Air Nozzles of air or steam has an extremely short effective spray angle, which is different from liquids.



Description
Model K1
Spray pattern Flat Fan
Thread size 1/4", 3/8"
Working pressure 3 bar
Thread Type NPT / BSPT
Material Stainless steel;brass;others
Application air compression:clean up dedusting,drying,air curtain,vapour,humidifying,conditioning.cooling.steam
Delivery time 4 Working Days after payment being confirmed
Payment Western union, Paypal, T/T, Visa, Our bank account, online payment



General Applications

● Cooling

● Drying

● Cleaning

● Air compression

● Dust removal

● Humidification



Design Features






Features:

● Air curtain angle blow-sweeping

● The flat fan air curtain sprays evenly

● A wide range of orifice diameter for option

● Groove structure makes nozzle spraying water or air and steam




K1

Thread dimension Slot witdth (mm) Air flow rate  (L/min) Vapour flow rate  (L/hour) The coverage 150mm to nozzle
1bar 2bar 3bar 7bar 1bar 2bar 4bar 7bar 1bar 4bar
L 0.20 21 38 65 102 0.75 1.4 2.3 3.7 275 419
P 0.33 41 60 99 153 1.5 2.1 3.6 5.5 152 254
Q 0.58 77 111 190 305 2.8 4.0 6.8 11.5 228 330
R 1.1 132 198 345 540 4.7 7.1 12.3 19.5 158 241
U 1.1 210 335 570 880 7.6 12.0 20.3 32 275 368
V 2.3 430 700 1150 1725 15.3 25 42 63 238 343



Ordering Information:

Thread size Style No. Material Flow Code


Example

1/4'' ZSTM 8 SS 120°
Thread size Style No. Material Spray Angle
