Plastic Air Compressor Mini Dry Fog Industrial Humidifier,Aeroponic Air Atomizing Fogger Spray Nozzle

Plastic Air Compressor Mini Dry Fog Industrial Humidifier,Aeroponic Air Atomizing Fogger Spray Nozzle
The material: stainless steel spray set-up, plastic body, ceramic nozzles. The typical application: humidifying,printing, coating, automotive, agriculture and livestock. It can be easily installed on a header, on a wall or on a ceiling.
Availability:
Product Description

Plastic Air Compressor Mini Dry Fog Industrial Humidifier,Aeroponic Air Atomizing Fogger Spray Nozzle



Product Name Plastic Air Compressor Mini Dry Fog Humidifier,Air Atomizing Fogger Spray Nozzle
Material Stainless steel, plastic
Orifice daimeter 0.35-0.5mm
Flow rate
2.4-3.3L/h
Work air pressure 0.3-0.35Mpa
Application Humidifying,printing, coating, automotive, agriculture and livestock


Dry Fog Industrial Humidifier Product Description

8


9
10

Humidifier use and maintenance


Pre-installation considerations

Make sure the water source and air source are clean.

Make sure the pipeline is clean.

Ensure that the compressed air is sufficient.

Impurities, oils, dust, etc. in water or gas can cause nozzle clogging. To achieve the best effect and longer life,

install a water filter at the water source and install an air filter at the air source.

Before installing the humidifier, drain the pipe. Dust, debris, and other contaminants in the pipes can clog the

nozzles. To keep air and water clean, use standard accessories and pipes that will not rust.

Humidifier single nozzle consumes 35L/min at 3 bar pressure. Make sure there is enough compressed air supply.

Longer or curved pipe, use larger pipe to compensate for pressure loss.

Precautions during use

For best use, use under 3 bar pressure. Water pressure should not exceed 4 bar.

Do not install or remove the nozzles at will, except for normal maintenance.

Routine maintenance methods

For safety, please disassemble with air and water closed.

If the nozzle is blocked and the spray effect is not satisfactory, please follow the steps below to clean:

Remove the nozzle from the tank. When rotating, please pay attention to the inside of the first to strongly

withstand the apron and then rotate.
